Model
Model |
Voltage Range |
Max Pressure |
Max Airflow |
||||
AC |
DC |
mmAq |
Watt |
L/min |
Watt |
||
| D126-1P-75 | Blowing |
110-240V 50/60Hz
|
310V | 1090 | 322 | 3100 | 641 |
| Suction | 1050 | 314 | 3100 | 660 | |||
| D126-1P-80 | Blowing |
110-240V 50/60Hz |
310V | 1010 | 293 | 3000 | 587 |
| Suction | 962 | 276 | 3000 | 588 | |||
| D126-2P-75 | Blowing |
110-240V 50/60Hz |
310V | 1990 | 444 | 2500 | 711 |
| Suction | 1780 | 387 | 2450 | 685 | |||
| D126-2P-80 | Blowing |
110-240V 50/60Hz |
310V | 1830 | 394 | 2500 | 643 |
| Suction | 1660 | 350 | 2400 | 631 | |||
Feature:
1. Variable speed available and low noise.
2. High efficiency and energy-saving.
3. Long life, low temperature rise, and durability.
4. Environmentally friendly operation and free maintenance.
5. Designed and made in Taiwan.
Motor protection:
1. Soft start protection
2. Overload protection
3. Locked-rotor protection
4. Over-voltage & lower voltage protection
5. Over-temperature protection
